Technical data for normal temperature type:DC-220V,TD-60% |
|
||||||||
|
Model |
MW22-11090L/G |
MW22-12090L/G |
MW22-12595L/G |
MW22-15065L/G |
MW22-140100L/G |
MW22-15075L/G |
MW22-17090L/G |
||
|
O.D. (mm) |
1140 |
1230 |
1280 |
1530 |
1400 |
1530 |
1700 |
||
|
Mass (kg) |
3020 |
3250 |
2830 |
2330 |
4100 |
2900 |
3500 |
||
|
Current (A) |
31 |
29.6 |
35.9 |
32.6 |
45.5 |
27.1 |
50 |
||
|
Power (kw) |
6.83 |
6.5 |
7.9 |
7.2 |
10 |
6 |
11 |
||
|
capacity |
Blooming billet (mm) |
200×200×12000 |
115×115×20500 |
256×295×12000 |
300×300×7000 |
115×115×21000 |
130×130×8000 |
150×150×12000 |
|
|
4 pcs |
8 pcs |
4 pcs |
2 pcs |
8 pcs |
8pcs |
10 pcs |
|
||
|
|
|
|
|
|
|
|
|
||
|
Girder billet (mm) |
500×250×10000 |
|
570×300×10000 |
-- |
|
|
|
|
|
|
2 pcs |
|
2 pcs |
|
|
|
|
|||
|
|
|
|
|
|
|
|
|||
|
Model |
MW22-15095L/G |
MW22-17065L/G |
MW22-17080L/G |
MW22-18090L/G |
MW22-20090L/G |
MW22-21065L/G |
MW22-25090L/G |
||
|
Outside Diameter (mm) |
1500 |
1700 |
1700 |
1840 |
2000 |
2150 |
2500 |
||
|
Mass (kg) |
4300 |
3160 |
3355 |
3390 |
6000 |
3770 |
6500 |
||
|
Current (A) |
39.1 |
32 |
33 |
34.8 |
59 |
44.7 |
59 |
||
|
Power (kw) |
8.6 |
7 |
7.3 |
7.7 |
13 |
9.8 |
13 |
||
|
Capacity |
Blooming billet (mm) |
300×400×10500 |
150×150×10000 |
240×320×10000 |
140×140×10000 |
330×550×10000 |
3 units 120×120×14000 |
330×550×10000 |
|
|
2 pcs |
8 pcs |
2 pcs |
10 pcs |
2 pcs |
15 pcs |
3 pcs |
|
||
|
|
|
|
|
|
|
|
|
||
|
Girder billet (mm) |
1120×400×10500 |
-- |
-- |
-- |
1200×400×10000 |
|
1200×400×10000 |
|
|
|
1 pcs |
1 pcs |
|
2 pcs |
|
|||||
|
|
|
|
|
|
|||||
