Technical Parameter of MW04 DC-36~ 110V, TD-60% |
||||||||
|
Model |
MW04-17T |
MW04-22T |
MW04-32T |
MW04-40T |
||||
|
Outside Diameter (mm) |
165 |
216 |
318 |
406 |
||||
|
Mass (kg) |
7 |
15 |
30 |
75 |
||||
|
Power (KW) |
0.1 |
0.2 |
0.25 |
0.4 |
||||
|
max. size material(mm) |
1200x1200 |
1400x1400 |
1600x1600 |
2500x2500 |
||||
|
Average size of material |
600x1200 |
700x1400 |
800x1600 |
1000x2500 |
||||
|
Attracting power |
thickness of plate |
δ 3.2 |
δ 5 |
δ 6 |
δ 10 |
δ 10 |
δ 32 |
|
|
peripheric fixing |
> 100kg |
> 200kg |
> 300kg |
> 600kg |
> 800kg |
> 4000kg |
||
