Model |
Erection height ( mm ) |
Belt width ( mm ) |
Dimensions |
Voltage ( V ) |
Power ( KW ) |
Mass ( kg ) |
Commutation Controlling unit |
|
|
Φ A |
H |
|||||||
|
MC03-30T(RCDB-3) |
100 |
300 |
300 |
600 |
DC-48 |
0.18 |
77.5 |
SSTM-0.5D-D |
|
MC03-40L(RCDB-3A) |
120 |
350 |
400 |
740 |
DC-50 |
0.48 |
120 |
|
|
MC03-50L(RCDB-4) |
150 |
400 |
500 |
700 |
DC-75 |
0.8 |
198 |
SSTM-1.5D-D |
|
MC03-60L(RCDB-5) |
180 |
500 |
600 |
1000 |
DC-110 |
1.15 |
318 |
|
|
MC03-70L(RCDB-6A) |
210 |
600 |
700 |
860 |
1.89 |
500 |
SSTM-3.1D-D |
|
|
MC03-80L(RCDB-6) |
250 |
650 |
800 |
900 |
2.36 |
640 |
||
|
MC03-90L(RCDB-8A) |
260 |
750 |
900 |
1140 |
2.48 |
968 |
||
|
MC03-100L(RCDB-8) |
290 |
800 |
1000 |
890 |
3.94 |
1070 |
SSTM-4.2D-D |
|
|
MC03-110L(RCDB-9) |
320 |
900 |
1100 |
1450 |
DC-220 |
4.1 |
1079 |
SSTQ-6.2D-D |
|
MC03-130L(RCDB-10) |
400 |
1000 |
1300 |
1200 |
6.18 |
2036 |
SSTQ-9.3D-D |
|
|
MC03-150L(RCDB-12) |
420 |
1200 |
1500 |
1350 |
8.58 |
3100 |
SSTQ-12D-D |
|
|
MC03-160L(RCDB-13) |
440 |
1300 |
1600 |
1400 |
9.5 |
3600 |
SSTQ-12D-D |
|
|
MC03-165L(RCDB-14) |
460 |
1400 |
1650 |
1500 |
10.5 |
4028 |
SSTQ-12D-D |
|
|
MC03-180L(RCDB-16) |
500 |
1600 |
1800 |
1640 |
11.1 |
4882 |
SSTQ-12D-D |
|
